Laptop Data Recovery

Coventry Data Recovery is the UK’s most experienced team for notebook data recovery, serving home users, businesses, and institutions for over 25 years. From minor logical corruption to catastrophic physical damage, we specialise in retrieving data from all makes and models of laptops and notebooks, using advanced forensic and cleanroom techniques.

---

💻 Supported Laptop & Notebook Brands

We recover data from all leading UK laptop brands, including:

1. HP – Pavilion, Envy, EliteBook, Spectre
2. Lenovo – ThinkPad, IdeaPad, Yoga, Legion
3. Dell – Inspiron, XPS, Latitude, Alienware
4. ASUS – ZenBook, ROG, TUF
5. Acer – Aspire, Swift, Predator
6. Apple – MacBook Pro, Air, Retina
7. Microsoft – Surface Laptop, Surface Book
8. Razer – Blade, Stealth
9. MSI – Creator, GE, GF, Modern Series
10. Samsung – Galaxy Book Series
11. Toshiba – Satellite, Tecra, Portégé
12. Fujitsu – Lifebook Series
13. LG – Gram Series
14. Huawei – MateBook Series
15. Dynabook
16. Packard Bell
17. Sony – VAIO
18. Medion
19. Alienware (Dell)
20. Chuwi / Other Emerging Brands

---

🧰 Our Services

We recover lost or inaccessible data from:

• Internal 2.5″ SATA HDDs
• NVMe and PCIe SSDs (M.2 / soldered)
• eMMC drives
• Mac Fusion drives
• External USB & Thunderbolt storage
• Dual-drive laptop configurations
• BitLocker and FileVault encrypted disks

All file systems are supported: NTFS, FAT32, exFAT, APFS, HFS+, ext4, and more.

---

⚙️ Top 30 Laptop & Notebook Faults – Recovery Methods Explained

Below are the most common notebook faults we resolve, with technical detail:

1. Accidental File Deletion

Issue: User permanently deletes files bypassing Recycle Bin.
Recovery: Use forensic tools to carve deleted data sectors before they’re overwritten. Metadata reconstructed from MFT (NTFS) or Catalog B-Tree (HFS+).

2. Formatted Drive

Issue: Quick or full format performed on system volume.
Recovery: Volume headers and file system structures are reconstructed. We scan for orphaned data blocks and recreate directory tree.

3. Partition Table Corruption

Issue: BIOS detects disk, but OS reports unallocated space.
Recovery: Use hex-level tools to manually restore lost GPT/MBR partitions using backup copies and known disk geometry.

4. Bad Sectors on Drive

Issue: Slow performance, failed read attempts.
Recovery: Clone disk using hardware-level imager with ECC bypass. Failed sectors are mapped, and data is extracted sector-by-sector.

5. Drive Not Recognised

Issue: BIOS or Disk Manager does not detect the drive.
Recovery: Diagnose for PCB failure or corrupted ROM chip. Replace PCB and reprogram firmware when required.

6. Physical Damage – Dropped Laptop

Issue: Head crash or platter misalignment.
Recovery: Drive opened in cleanroom, heads replaced from donor match. Disk imaged to prevent further damage.

7. Water or Liquid Damage

Issue: Spilled liquid shorts internal circuitry.
Recovery: Disassemble drive, dry components. Clean corrosion with isopropyl wash and recover from pre-damage disk image.

8. SSD Controller Failure

Issue: No detection; drive shows 0GB.
Recovery: BGA NAND chips removed and read with chip reader. Data reconstructed using vendor-specific translation algorithms.

9. Virus or Malware Infection

Issue: Files hidden, deleted or replaced.
Recovery: Identify infection pattern, isolate damaged sectors. Use signature-based file carving to recover deleted/renamed files.

10. Overwritten Data

Issue: New files saved over deleted space.
Recovery: Partial recovery via entropy analysis. Reconstruct fragments using file headers/footers (e.g., JPEG, DOCX, PST).

11. MacBook SSD Not Mounting

Issue: APFS container corruption.
Recovery: Rebuild container from backup superblocks, reconstruct volume layout using Disk Warrior / APFS tools.

12. BitLocker Encrypted Drive with Lost Key

Issue: Cannot access drive.
Recovery: Brute-force dictionary attack (if passphrase suspected), TPM analysis, key recovery from backup sectors.

13. File System Corruption

Issue: Incomplete writes or improper shutdowns.
Recovery: Repair file system with forensic utilities (TestDisk, R-Studio), rebuild lost index tables.

14. BIOS/UEFI Boot Error

Issue: “No Bootable Device” or similar error.
Recovery: Extract full disk image, restore bootloader (MBR/EFI), and recover OS partitions.

15. Head Crash (HDD)

Issue: Clicking noise, no detection.
Recovery: Replace head assembly in ISO-5 cleanroom. Calibrate heads and image to bypass further mechanical contact.

16. Platter Damage

Issue: Rattling sound or unreadable data.
Recovery: Attempt imaging using adaptive heads. If damage is severe, sectors are skipped and non-damaged data extracted.

17. PCB Failure (Short Circuit)

Issue: No spin-up or detection.
Recovery: Replace PCB with identical model; transfer ROM chip. Secure power input and test voltage levels.

18. Connector or Port Damage

Issue: USB-C / SATA connectors bent or loose.
Recovery: Directly access NAND or SATA terminals on PCB. In some SSDs, adapter-based extraction is performed.

19. Unsupported File System

Issue: OS shows “You must format this drive…”
Recovery: Identify and mount using forensic software. Convert or interpret file system layout and extract raw data.

20. Controller Chip Overheating (SSD)

Issue: SSD freezes intermittently.
Recovery: Use temperature-controlled platform to stabilise controller. Recover by imaging before it fails thermally.

21. Overheated System Crash

Issue: Long-term use causes thermal throttling, shutdown.
Recovery: Analyse SMART logs. Identify weak sectors caused by heat stress and perform stabilised clone.

22. Stuck Spindle Motor (HDD)

Issue: Drive spins inconsistently or vibrates.
Recovery: Spindle realigned using head-freezing techniques, then carefully disassembled for platter transfer if needed.

23. Soldered SSD (eMMC) in Netbooks

Issue: No standard port access.
Recovery: Access chip via test points or desolder, read using eMMC reader, reconstruct partitions.

24. Memory Card Not Recognised (Card Readers in Laptops)

Issue: SD or microSD shows “corrupt” or “unreadable.”
Recovery: Image raw card; identify and reconstruct file allocation tables.

25. Controller Firmware Bug

Issue: Vendor firmware locks drive or causes crash.
Recovery: Update or downgrade firmware; manually read chip using SPI interface.

26. File Transfer Interrupted

Issue: Partial file copy results in corruption.
Recovery: Restore original state via journaling system; undelete via metadata tables.

27. Laptop Won’t Power On (Drive Still Intact)

Issue: Power button or motherboard issue.
Recovery: Remove and access storage via external interface or direct NAND extraction.

28. Partition Reinitialised

Issue: Accidental reinstallation of OS.
Recovery: Search unallocated space for signature-based files. Rebuild directory tree if file system is partially intact.

29. Manufacturing Defects (Firmware Loops, SandForce Errors)

Issue: SSD locked in bootloader mode.
Recovery: Force firmware handshake, unlock using vendor tools, rebuild FTL (Flash Translation Layer).

30. S.M.A.R.T. Failures

Issue: Imminent drive failure indicated.
Recovery: Image drive using slow read with retry, bypass weak sectors, and reassemble logical structure from clone.

---

💽 Why Choose Coventry Data Recovery?

• 25+ Years Experience in Notebook Data Recovery
• Fully Equipped Cleanroom
• Expertise in HDD, SSD, eMMC, NVMe Recovery
• Forensic-Grade Recovery for Legal & Critical Data
• Fully Compliant with UK Data Protection (GDPR)
• Fast-Track & Emergency Services Available

From failing school laptops to business-critical notebooks, we have the tools, skill, and knowledge to recover your data successfully and securely.

---

📞 Contact Coventry Data Recovery Today

If your laptop or notebook has failed or your files have become inaccessible, stop using the device immediately. Continued operation may overwrite or damage recoverable data.

Contact Coventry Data Recovery now for a FREE diagnostic. We are the UK’s trusted name in expert-level notebook data recovery.
